The PR1012 Serial Contactless Reader Module with SAM Slot was designed based on 13.56 MHz technology for fast and easy integration into embedded systems. It is a plug-and-play device that does not require any driver installation.
PR1012 supports ISO 14443 Parts 1-4 Type A and B cards, and MIFARE® Classic series. It has a card reading distance of up to 50 mm (depending on tag type). Moreover, it has an ISO 7816-compliant built-in SAM (Secure Access Module) slot, which can be used with a SAM card for high-level security in contactless transactions.
This reader module with integrated (on-board) antenna comes with an optional serial cable. It has additional features like USB firmware upgradability and extended APDU support. Lastly, PR1012 makes use of high-speed communication for contactless cards (maximum of 848 kbps), which makes it suitable for highly demanding applications. Its RS232 serial interface can accommodate more devices, such as vending machine payment systems, kiosks, gaming machines, and other integrated systems, which have different serial ports.
Features
- Serial RS232 Interface
- USB interface for power supply
- CCID-like frame format (binary format)
- USB Firmware Upgradeability
- Smart Card Reader:
- Contactless Interface:
- Read/write speed up to 848 kbps
- Built-in antenna for contactless tag access, with card reading distance of up to 50 mm (depending on tag type)
- Supports ISO 14443 Part 4 Type A and B cards and MIFARE® Classic series
- Built-in anti-collision feature (only 1 tag is accessed at any time)
- Supports extended APDU (max. 64 kbytes)
- SAM Interface:
- ISO 7816-compliant SAM slot, Class A (5V)
- Peripherals:
- 2 user-controllable single-color LEDs
- 1 user-controllable buzzer
Technical Specifications
| Physical Characteristics | |
|---|---|
| Dimensions (mm) | 106.6 mm (L) x 67.0 mm (W) x 16.0 mm (H) |
| Weight (g) | 20.8 g |
| Serial Interface | |
|---|---|
| Connector Type | DB-9 Connector |
| Protocol | RS-232 |
| Power Source | Via USB cable |
| Cable Length | 1.5 m, Detachable (Upon Request) |
| Contactless Smart Card Interface | |
|---|---|
| Standard | ISO 14443 A and B Parts 1-4 |
| Protocol | ISO14443-4 Compliant Cards, T=CL; MIFARE® Classic Card Protocol, T=CL |
| Antenna | 65 mm x 60 mm |
| SAM Card Interface | |
|---|---|
| Number of Slots | 1 |
| Standard | ISO 7816 Parts 1-3, Class A (5 V) |
| Protocol | T=0; T=1 |
| Built-in Peripherals | |
|---|---|
| LED | 2 single-color: Red and Green |
| Buzzer | Monotone |
| Other Features | |
|---|---|
| Firmware Upgrade | Supported |
| Certifications/Compliance | |
|---|---|
| Certifications/Compliance | ISO 7816 (SAM Slot), ISO 14443, CE, FCC, RoHS, REACH |
| Device Driver Operating System Support | |
|---|---|
| Device Driver Operating System Support | Windows®, Linux® |
Downloads
| Type | Title | Size | Updated |
|---|---|---|---|
| Driver | Library Package (Windows® XP through Windows® 11 / Server editions) | 195.00 KB | 18-Apr-2024 |
| Driver | Library Package (Linux®, Mac OS® X 10.5–10.9) | 987.50 KB | 18-Apr-2024 |
| Brochure | Product Presentation of ACM1281S-C7 Serial Contactless Reader Module with SAM Slot | — | — |
| Datasheet | Technical Specification of ACM1281S-C7 Serial Contactless Reader Module with SAM Slot | — | — |
| Manual | Reference Manual of ACM1281S-C7 Serial Contactless Reader Module with SAM Slot | — | — |
| Manual | User Manual of ACM1281S-C7 Serial Contactless Reader Module with SAM Slot | — | — |
