PR1064 — FIDO® Certified USB Security Key with Fingerprint
FIDO® Device

PR1064

FIDO® Certified USB Security Key with Fingerprint

FIDO® Certified USB security key with fingerprint recognition for passwordless authentication

Manufacturer reference: ACS — PocketKey+ Bio ↗. PR codes identify Elvantic catalogue entries. Manufacturer documents and driver identifiers retain their original names.

  • FIDO2 L1
  • FIDO U2F

Primary Applications

  • Enterprises
  • Financial Services & Payments
  • e-Government
  • Healthcare & Insurance

PR1064

Plan your purchase

Choose the next step for your project. Include your requirements so the enquiry can address the right model and configuration.

Evaluation samples
Paid samples
Warranty
One-year warranty

Confirm sample pricing, the exact configuration, warranty handling and shipping terms in the quotation or order.

What to include in your enquiry

Model and quantity
Specify the model or required function, evaluation quantity and expected order quantity.
Destination and application
Include the delivery country, project use and required delivery date.
Cards and host platform
List the card or tag type, operating system and version, connection and software requirements.

Questions to resolve before ordering

  • Which card, tag or identity document must the product work with, and what data must be read or written?
  • Which host device, operating system and application will use it? Confirm compatibility with your intended setup before ordering.

If you need an SDK or development kit, specify the hardware and software items required, and ask for confirmation of kit contents and licence terms.

Overview

PR1064 lists USB-C and NFC connectivity, with a fingerprint sensor for USB use.

Fingerprint verification is available via USB only, not NFC. Evaluate the service's verification policy and the intended connection separately.

Features

  • Ultra-portable form factor with 2-in-1 connectivity: - USB Type-C connector - NFC Interface
  • Security Feature: - FIDO2 Authenticators - Biometric Authentication - Data protection
  • Enhanced Biometric Experience: - Quick and Easy Finger Registration - Supports Up to 10 Fingerprints
  • Plug & Play
  • Passwordless Login

Technical Specifications

Physical Characteristics
Dimensions (mm) 34mm (L) x 18mm (W) x 7.8mm (H)
Weight (g) 4.2 g ± 1 g
USB Interface
Protocol USB HID
Connector Type USB Standard Type-C
Speed USB 2.0 Full Speed (12 Mbps)
NFC Interface
ISO 14443 Type A Support
Biomatric Performance
Biomatric (Fingerprint) Support (Available via USB interface only; NOT supported over NFC)
False Reject Rate (FRR) < 1.2%
False Acceptance Rate (FAR) < 1:50k
Acquisition time < 100ms
Contact Smart Card Interface
Supply Current Max. 100mA
Cryptographic Specification ECC p256
Built-in Peripherals
LED 1 x LED (Blue)
User Interface Fingerprint Sensor
Other Features
Other Features Enterprise Attestation: Upon Request
ACS FIDO Key Manager: Supported
Fingerprint Storage 10
Passkeys (FIDO2) slots 100
ACS OTP Support
OATH – HOTP Support
OATH – TOTP Support
Security Authenticators: FIDO2, FIDO2 CTAP2
Certifications/Compliance
Systems/Standards FIDO2 L1, FIDO U2F
Regulatory/Environmental CE, UKCA, FCC, RoHS, REACH
Device Driver Operating System Support
Device Driver Operating System Support OS support: Windows®, Linux®, macOS, Android™ and iOS. Browsers: Chrome™, Safari®, Microsoft Edge® and Firefox®. Platforms: Microsoft®, Apple ID®, iCloud®, Facebook and Google®
